Wireless Grade 3 solution

The world's first wireless intrusion protection for high-security sites

Ajax Superior products are available exclusively to accredited Ajax Systems partners for sales, installation, and maintenance, creating a protected, high-value revenue channel.

Compliance proven by certificates

High security. Now wireless.

Completely wireless connectivity

Just one power cable and Ethernet — that's all the system needs. The rest is pure freedom: a fully wireless device portfolio ready to support every installation scenario.

The fastest deployment in the industry

No cables, no downtime — just a 2-minute setup per device. The system is connected and configured via Ajax apps, delivering stable, certified operation from day one.

Endless capabilities of the Ajax ecosystem

The system can be easily adapted to each project's specific needs. Ajax products for video surveillance, automation, fire safety, and even third-party devices can be integrated with wireless Grade 3 devices to build a powerful security solution.

Accurate detection with near-zero false alarms

Advanced Ajax algorithms respond instantly to real threats and ignore the rest. With Grade 3 precision and lightning-fast communication protocols, alarms reach monitoring stations in less than a second.

Grade 3 level sabotage resistance

Each device features a tamper button that responds immediately in case of attempts to dismount or detach the device. The hub continuously supervises detector states and identifies communication loss in just 36 seconds. With enhanced anti-masking, jamming detection, frequency hopping, and data encryption, Ajax G3 devices are ready to resist any sabotage attempts.

Tested and certified performance

Ajax G3 devices don't just claim Grade 3 — they prove it. Each one is thoroughly tested and certified to EN 50131 (Grade 3) by independent labs in Europe, confirming compliance with the highest globally recognized security standards. Together, these devices create a stronghold of wireless protection that remains reliable in any setting.

Testing in real-world conditions

The certification process evaluates the entire system operating in real conditions, not only individual components.

Stable communication between devices

Reliable and secure data exchange between all system components is ensured with enhanced communication protocols.

Automatic fault reporting

The system instantly detects and reports faults, whether it's a sensor malfunction, masking attempt, or power issue.

Grade 3 sabotage protection

Jamming detection and frequency hopping

The hub continuously monitors the quality of wireless communication with system devices. If jamming is detected, the hub automatically switches between 17 available frequencies across 4 European bands. At the same time, it sends a jamming alert to both users and the monitoring company.

Masking detection

Ajax G3 motion detectors feature anti-masking technology that identifies attempts to block their view — even when the system is disarmed. They detect masking by fabric, paper, metal, or aerosols. Opening detectors use a magnetometer to track changes in the surrounding magnetic field and immediately detect tampering by using strong magnets.

Autonomous operation in a blackout

In the event of a power outage, mains-powered devices instantly switch to backup power, while other devices continue running on built-in batteries — keeping the system fully operational and energy-independent.

Data encryption

All data transmitted between system devices via proprietary radio protocols is encrypted. Each device uses individual authentication methods, making unauthorized reprogramming or data theft extremely difficult. Communication between the hub and Ajax Cloud is established through the proprietary HtS protocol, which is secured by NIST-certified AES-128 encryption.

Communication failure detection

Each system device regularly exchanges data with the hub and can send three data packets as often as every 12 seconds. If the connection is lost, the system detects it in only 36 seconds and notifies the security company and users about the incident.

Device authentication to prevent spoofing

The hub automatically verifies each device's unique parameters during every communication session. If any parameter fails authentication, the hub ignores all commands from that device.

Protection against code guessing and access devices copying

Ajax G3 keypads respond only to access devices authorized via Ajax apps. The DESFire® chips in cards and key fobs comply with ISO 14443 and combine 128-bit encryption with copy protection. The BLE reader ignores smartphones that are not authorized in Ajax apps. To prevent code guessing, the system locks the keypad after three failed attempts for a set period and immediately reports the incident.

Ajax devices feature a tamper button that triggers an alarm if the device is dismantled or detached from the surface. Some devices have additional tamper buttons that respond to the enclosure being opened or damaged.

Advanced system supervision

All Ajax devices perform automatic self-diagnosis and report their states to the hub. Essential parameters, including tamper, communication, power supply, and sensor statuses, are continuously monitored. The Ajax Cloud server controls communication between the hub and Ajax apps, ensuring instant notifications for monitoring stations, security companies, and users in case of any fault or communication failure.

Detection without compromise

Ajax Superior devices detect real threats with near-zero false alarms. Motion detectors have an extremely small 30 cm (0.98 ft) blind zone, reliably capturing crawling, fast, or slow movement. Opening detectors respond to shock and tilt for early intrusion detection, while panic buttons trigger alarms with no wake-up delay. Continuous supervision and regular sensor health checks ensure timely fault and maintenance notifications, and the anti-masking system reacts to any attempt to cover or sabotage a device.

Wireless Grade 3 motion detectors do not feature pet immunity, as their ultra-precise detection technology covers the entire area without leaving blind spots for intruders.

Covering a wide range of high-security sites

Designed for small- to medium-sized facilities, the solution supports up to 250 devices in a single system. It's ideal for high-security projects and installations that require enhanced protection, even when formal certification is not mandatory.

Manufacturing facility

Government institution

Medical laboratory

The Ajax portfolio includes Superior MegaHub — the flagship control panel designed for building setups of any configuration and complexity. Supporting up to 999 devices and 100 security groups, it can combine wired and wireless Grade 3 devices into a single system, delivering enterprise-scale protection.

Explore the complete product portfolio

Ajax Superior Hub G3 Jeweller is the first fully wireless control panel certified to Grade 3 standards. It's easy to install, simple to use, and requires minimal maintenance. With built-in communicators and wireless device connectivity, the system can be deployed quickly and connected to monitoring stations via Ajax apps. The hub also supports Ajax fire safety, video surveillance, and automation, making it a unified solution for high-security sites.

Explore features and specs

Fully wireless connectivity with a range of up to 11,450 ft

Built-in communicators for internet connection and data exchange with system devices

Always online via Ethernet, Wi-Fi, and two SIM cards 2G/4G (LTE)

Superior Jeweller, TurboWings, and VoRF radio protocols for device communication

Support for 250 devices, 200 users, 25 security groups, and 64 automation scenarios

Support for intrusion protection, automation, fire safety, and video surveillance devices in any combination

Range extenders

The range extender increases wireless coverage between the hub and connected Ajax devices. It can connect to the hub via proprietary radio protocols or Ethernet, ensuring stable communication even in challenging areas — such as basements, remote spaces, or metal structures.

Up to 11,450 ft of additional radio communication range

Ethernet connectivity for challenging radio signal environments

Up to 5 range extenders per hub for expanded coverage

Superior Jeweller and TurboWings radio protocols for device communication

Opening detectors

Ajax Superior DoorProtect G3 Jeweller uses two reed switches as opening sensors and a magnetometer to detect magnet spoofing. A built-in accelerometer responds to vibration, shock, and tilt, ensuring window protection even in tilt mode. The detector effectively filters out false alarms and resists sabotage, making it ideal for sites with higher security requirements.

Two reed switches: the magnet can be placed on either side of the detector

Shock and tilt detection powered by a built-in accelerometer

Reed switch chattering protection to prevent false alarms

Adjustable shock and tilt sensors for precise detection

Up to 4 years of operation on pre-installed enhanced batteries

Protection against magnet spoofing with a built-in magnetometer

Motion detectors

The product group includes two detectors: one with a PIR sensor and one combining PIR with a K-band microwave sensor. Both devices detect slow and fast motion at distances up to 49 ft , including crawl-under attempts. An advanced anti-masking system responds instantly to detector blinding — whether by an object, paint, or tape.

Up to 49 ft of motion detection distance

Minimized blind zone of 0.98 ft to detect crawling

Accurate detection of both slow and fast movement

SmartDetect software algorithm and three sensitivity levels to minimize false alarms

Advanced anti-masking system to detect lens covering, painting, or obstruction

Up to 5 years of operation on pre-installed enhanced batteries

Three built-in tamper buttons

Wireless Grade 3 motion detectors do not support the pet immunity feature.

Motion detectors with camera

Ajax Superior MotionCam G3 (PhOD) Jeweller detects anyone sneaking or rushing up to 49 ft away, crawling beneath the detector, or trying to obstruct the sensors. Within seconds, the device captures evidence and delivers a photo series to the monitoring station and system users to provide a clear view of the scene.

Support for various types of photo verification

Support for HD photos with 960 × 720 px resolution and HDR technology for high-quality images in challenging lighting

Up to 6 years of operation on pre-installed enhanced batteries

Two built-in tamper buttons

The product group includes two keypads: one with a touch panel and one with a touch screen. Both models feature DESFire® technology for contactless access and support multiple code types to ensure a secure and convenient experience for users.

Security mode control and automation management

Support for contactless access devices featuring DESFire® technology

Contactless control via smartphone using BLE (for the touchscreen model)

Remote management of access rights, devices, and codes via Ajax apps

Multiple types of access codes

5-inch display with a 480 × 854 px resolution (for the touchscreen model)

Sound and LED notifications of alarms and events (for the touchscreen model)

Up to 4.5 years of operation on pre-installed enhanced batteries

Ajax Superior DoubleButton G3 Jeweller is a hold-up device. Both buttons must be pressed simultaneously to trigger an alarm, with a plastic divider preventing accidental activation. The device can be carried as a key fob or mounted on a flat surface using the Holder accessory (sold separately).

Protection against accidental activation: alarm is triggered by simultaneous press of two separated buttons

Alarm confirmation to prevent false dispatches: by a second press or another hold-up device

Automatic daily battery health checks and low battery notifications

Support for automation scenarios initiated by button alarm and confirmed button alarm

IP55-rated enclosure

Wireless Grade 3 sirens alert users to intrusions and deter trespassers with a loud buzzer and bright LED indicators. The product group includes two sirens: one for indoor use only and one for outdoor installation. Both sirens also report opening doors, entry/exit delays, and past alarms in the system. The devices also feature enhanced protection against sabotage and detect jamming attempts.

Adjustable alarm volume and duration with multiple selectable sound patterns

Bright built-in LED frame (for the outdoor model) or single LED indicator (for the indoor model)

LED and sound indication of security mode changes and entry/exit delays

Chime feature and after-alarm LED indication

Jamming detection and frequency hopping to prevent radio interference

Up to 10 years of operation on pre-installed enhanced batteries

Integration modules

Ajax Superior MultiTransmitter G3 Jeweller modernizes existing security setups by adding core Ajax ecosystem benefits: centralized management via Ajax apps, informative notifications, integration with video surveillance, fire safety, and automation devices. All this works without changing the existing layout, wiring, or device configuration. The module can also expand an Ajax system with nearly any third-party security device.

18 zones with NC, NO, EOL, 2EOL, and 3EOL connection types

Over 10 configurable event types for connected devices

KeyArm Zone input for controlling system security modes

Automatic EOL resistance measurement

Support for automation scenarios triggered by connected devices

5 outputs for a 12 V⎓ power supply: one isolated line for fire detectors and four for other devices

Up to 1,300 ft of wired connection range between devices and the integration module

Choose the professional-grade solution

Find your trusted security systems provider and get wireless G3 products

All communicators built in

All wireless Grade 3 devices come fully equipped with all necessary communicators — no additional modules needed. Built-in radio modules provide seamless connectivity between the hub and system devices. Alarms and events are sent from the hub to the monitoring station and Ajax apps via Ethernet, Wi-Fi, or cellular communication.

Cellular: 2 × SIM 2G/4G (LTE)

Unique wireless technologies

Learn more about Ajax wireless technologies

Transmits alarms, events, and readings to Ajax apps in just 0.15 seconds.

Delivers photo verification and large data packets over long distances.

Ensures real-time voice data exchange between the hub and voice modules.

Radio communication range of up to 11,450 ft in open space

Grade 3 level reliability with strong encryption

Jamming detection and advanced frequency hopping

Automatic data packets resending in case of delivery failure or connection loss

Wireless Grade 3 hub and range extender also support Jeweller and Wings protocols.

Installation experience beyond standards

Adding devices to the system

There is no need to disassemble the enclosure: all devices are easily mounted on the SmartBracket panel. The installation kit includes all necessary fasteners, enabling installers to mount devices on walls or ceilings with ease.

Installation without enclosure disassembly

All fasteners included in the complete set

Pre-installed batteries work out of the box — no need to remove isolating tabs

Ajax apps help integrate new devices into the ecosystem in no time. Simply scan the QR code or enter the device ID manually. Once added, devices receive a default name and settings suitable for most use cases. Everything is configured via toggles in an intuitive interface, eliminating the risk of human error.

Adding to the system by scanning a QR code

All settings configured via Ajax apps

Optimal default settings to cover major requests

Intuitive Ajax apps enable remote device maintenance and testing from anywhere with an internet connection, using a smartphone or computer. Installers can adjust settings and provide service promptly without visiting the site.

Remote or on-site configuration and testing

Apps for iOS, Android, macOS, and Windows

Accounts for companies and installers

Breaking old ways with powerful apps

Ajax PRO: Tool for Engineers

Mobile app for professional Ajax system installation, configuration, and maintenance

Ajax PRO Desktop

Desktop app for centralized incident monitoring and streamlined security operations

macOS Apple Silicon

Desktop app for everyday Ajax system management and oversight

Ajax Security System

Mobile app for everyday Ajax system management and oversight

Built for intrusion protection. Ready for much more.

Wireless Grade 3 solution offers flexibility to build a comprehensive security setup controlled by a single hub. The system can operate as a standalone intrusion alarm or as part of an integrated setup that combines intrusion protection, automation, video surveillance, and fire safety.

Intrusion protection

Video surveillance

Compliance with EN 50131 (Grade 3)

The world's first fully wireless system compliant with Grade 3

Instant detection of motion, opening doors and windows

Visual alarm verification for faster threat identification and response

System control via keypads or Ajax apps

Enhanced sabotage protection

Explore wireless Grade 3 devices

Visual verification of every alarm in the system

Compliance with NDAA

Secure video streaming with encrypted data transmission

Live view and archive access via Ajax apps

Night vision with IR and white LED hybrid illumination

ONVIF compatibility for third-party NVR and VMS support

Explore Ajax video devices

Water leak detection and water supply control

Air quality monitoring

Automation scenarios for routine tasks and on-site security

Power control for lighting and third-party appliances

Intuitive in-app control

Integration and control of roller shutters, electric locks, and other third-party equipment

Explore Ajax automation devices

Reliable detection of smoke and rapid temperature rise

Audible and visual indication that meet strict regulatory requirements

Automated control of fire safety and evacuation equipment during alarms

System management via Ajax apps

Explore Ajax fire safety devices

Monitoring without hassle

Ajax systems transmit alarms to the Ajax PRO Desktop monitoring app or any third-party software in less than a second. Notifications include all essential details: the device name, location, and event time. The monitoring company also receives photo or video verification to clearly determine the alarm cause.

Full addressability of connected devices

Instant notifications

Alarm monitoring via Ajax PRO Desktop or third-party monitoring software

Support for a wide range of event transmission protocols, including SIA DC-09 and SurGard (Contact ID)

Ajax PRO Desktop is an app for system installation, monitoring, and management. It meets the needs of every security business working with Ajax systems. Facility profiling, alarm monitoring, photo verification, staff administration, and a detailed event log — all in one intuitive app with support for remote configuration.

Useful resources

Wireless Grade 3 product catalogue

Brochure on wireless Grade 3 solution

Demo video for engineers and PRO users

More Ajax superpowers

Visual verification of alarms

The hub supports photo and video alarm verification via Ajax MotionCam detectors and security cameras. Integrated in one powerful system, this device combination does the trick. It helps quickly assess the situation, saving users from concerns and monitoring companies from unnecessary patrol dispatches.

Instant photo and video evidence from triggered devices

Seamless delivery of visual proof to monitoring software

Automation for greater safety

Ajax Superior Hub G3 Jeweller supports up to 64 automation scenarios, enabling flexible configuration to meet the specific safety requirements of each site. The hub can arm or disarm the system by schedule, while scenarios can automatically respond to specific events — for example, activate a smoke machine when someone enters the premises, shut off water in case of a leak, or start ventilation if the CO₂ levels rise. Lights, electric locks, roller shutters, and garage doors can be controlled by schedule, arming/disarming, button press, or detector alarm.

Support for a wide range of devices

Support for multiple automation scenario types

Scenario activation by an alarm or a confirmed alarm

Ajax solution for retrofitting an outdated burglar alarm

Transform an outdated burglar alarm into an intelligent security system. Existing security devices that are still operational can be combined with Ajax solutions to create a single, cost-effective system with modern capabilities. There is no need to rewire the entire facility: wired Ajax devices can reuse the existing infrastructure, while wireless devices expand the setup with minimal installation time. Users benefit from enhanced security, data-rich notifications, automation scenarios, and a whole new level of control via Ajax apps.

Reuse of the existing wire infrastructure — no new cabling required

Support for both standalone third-party devices or entire systems

Integration with full Ajax ecosystem functionality — from scenarios to visual verification

Add value and grow revenue with Ajax Services

Ajax SIM: stable connection with no effort

Ajax SIM provides instant and reliable cellular communication right out of the box. No complicated setup, no tricky activation — the SIM card does almost everything on its own. Unlimited traffic and reliable connection are available from the very first minute of operation.

More info for PROs

Ajax Ultra DP: dual-path reliability with ready-to-use presets

Ajax Ultra DP offers a simple way to configure compliant dual-path alarm transmission (DP2, DP3, or DP4). It complements Ajax SIM to deliver reliable and uninterrupted system operation from the very start. All is up and running within minutes thanks to quick and intuitive in-app setup.
