Milesight Red Light Enforcement Solution

AI-Powered Automated Enforcement for Safer Intersections and Smarter Traffic Management

Red Light Enforcement Solution

The Challenge: Red Light Running Remains One of the Deadliest Intersection Violations

Running a red light is among the leading causes of severe intersection crashes worldwide. These violations often result in high-speed side-impact collisions, causing serious injuries and fatalities to drivers, passengers, pedestrians, and cyclists.

According to the Insurance Institute for Highway Safety (IIHS), 1,086 people were killed in red-light-running crashes in the United States in 2023 , while more than 135,000 people were injured . Nearly half of those killed were occupants of other vehicles, pedestrians, bicyclists, or other innocent road users.

1,086 fatalities caused by red-light-running crashes in 2023

Over 135,000 injuries annually

Nearly 50% of victims are not the violating drivers

Fatal red-light-running crashes continue to increase in many urban areas

Traditional Enforcement vs. AI-Powered Enforcement: Why Traditional Red Light Cameras Are No Longer Enough?

Traditional Red Light Camera

Requires radar, loop detectors, or embedded road sensors

Complex road construction and maintenance

High deployment and maintenance costs

Manual violation verification required

Heavy reliance on operator review

Limited scalability

Separate hardware components

Milesight Red Light Traffic Camera

Pure AI video analysis with optional signal controller integration

Minimal infrastructure modification

Lower installation and operational costs

Automated AI-based violation determination

Automated enforcement workflow

Easily scalable citywide

All-in-one intelligent camera solution

Milesight Solution: End-to-End Automated Red Light Enforcement Camera

Accurate signal status recognition is the foundation of reliable enforcement. Milesight Red Light Enforcement Camera supports two independent signal recognition methods that can be used individually or simultaneously.

Directly connect the traffic signal controller through 4-channel external input interfaces.

Highest reliability

Suitable for complex intersections

Immune to lighting conditions

Direct synchronization with signal controller outputs

Video-Based Signal Analysis

AI algorithms automatically recognize the ON/OFF status of two traffic signal groups directly from video streams.

No physical wiring required

Lower installation cost

Faster deployment

Greater flexibility for retrofit projects

Milesight Red Light Enforcement Camera supports multiple trigger conditions that can be configured independently according to local enforcement requirements.

In the Lane: Vehicle remains inside the lane during the red phase.

Vehicle Front Crossed the Stop Line: Vehicle front bumper crosses the stop line.

Vehicle Tail Crossed the Stop Line: Entire vehicle passes beyond the stop line.

Reached the Trigger Line: Vehicle reaches a predefined trigger position inside the intersection. Independent trigger lines can be configured for: Straight movement, Left turns, Right turns.

Red Light Running

Milesight Red Light Traffic Camera accurately detects vehicles that cross the stop line after the traffic signal has turned red .

By combining real-time traffic signal recognition with vehicle trajectory analysis, the camera automatically captures violations and generates comprehensive evidence packages , helping authorities improve intersection safety and streamline enforcement operations.

False Start Detection

Milesight Red Light Camera can identify vehicles that begin moving before the green signal is activated and cross the stop line while the signal is still red .

To ensure clear differentiation from standard red-light-running violations, the generated evidence snapshots explicitly indicate the corresponding signal status and event type .

This helps enforcement agencies accurately classify violations, reduce disputes, and maintain fair enforcement practices.

Red-Light Grace Period

To support fair and accurate enforcement, Mileisght Red Light Violation Detection Camera provides a configurable grace period ranging from 0 to 3000 ms .

This adjustable tolerance helps accommodate vehicle braking inertia and real-world driving conditions , effectively reducing false violations caused by unavoidable stopping delays while ensuring a more reliable and human-centered enforcement process.

Multi-Snapshot Evidence Package

Milesight Red Light Violation Detection Camera automatically captures a series of key moments throughout the violation and generates evidence snapshots embedded with essential information such as timestamp, location, license plate number, and traffic signal status.

A typical evidence package includes six images:

Four Violation Progression Snapshots: These sequential snapshots clearly illustrate the vehicle's movement throughout the violation process, including:

Vehicle remaining within the lane before crossing the stop line during the red phase

Vehicle front crossing the stop line

Vehicle rear crossing the stop line, indicating the entire vehicle has entered the intersection

Vehicle reaching a predefined trigger line within the intersection

One Vehicle Overview Image: A full-view image of the vehicle, enriched with attributes such as vehicle type, brand, model, and body color.

One License Plate Close-Up: A high-resolution license plate image that ensures accurate vehicle identification and supports reliable enforcement.

Full Violation Video Recording

In addition to static snapshots, Mileisght Red Light Enforcement Camera automatically records and stores a high-definition video covering several seconds before and after the violation event . The video provides a continuous view of the entire process, including:

Vehicle approaching the intersection

Traffic signal transition

Failure to stop before the stop line

Vehicle crossing the stop line and proceeding through the intersection

By presenting the complete sequence of events, the video serves as an intuitive and tamper-resistant record that complements the captured snapshots.

A Closed-Loop Evidence Framework

The evidence package combines the strengths of both snapshots and video recordings . While snapshots preserve critical moments and key details such as license plates, signal status, and vehicle positions, the video provides a continuous visual narrative of the violation.

Together with automatically embedded metadata such as GPS location and precise timestamps , they form a robust, closed-loop evidence chain that ensures every enforcement decision is transparent, verifiable, and supported by clear proof.

Detect Signal Failures Before They Disrupt Traffic Flow

Unlike conventional red-light enforcement cameras that focus solely on violations, Milesight goes a step further by continuously monitoring the operational health of traffic signals , helping authorities detect issues early and maintain safe and efficient intersection control.

Supported Signal Fault Detection Types

Milesight Red Light Enforcement Camera automatically identifies abnormal signal behaviors, including Light Up Simultaneously , where conflicting signals are illuminated at the same time; All Light Off , indicating a complete signal outage; and Light Flashing , which detects irregular or unstable flashing patterns. These fault types are continuously analyzed in real time to ensure accurate detection of signal malfunctions.

Real-Time Events Response

Once a signal anomaly is detected, Milesight Red Light Enforcement Camera immediately generates alarm events and can push notifications to third-party management platforms . It also triggers video recording to preserve on-site evidence and supports maintenance teams with rapid diagnostics, enabling faster response and minimizing downtime.

Why Choose Milesight Red Light Enforcement Camera?

AI-Based Detection Without Road Sensors

Milesight leverages advanced video AI to detect violations without relying on inductive loops, radar, or other road-embedded sensors. This significantly reduces civil construction requirements and simplifies deployment and maintenance.

Complete Snapshot + Video Evidence Chain

The solution provides both multi-frame snapshots and continuous video recording to form a complete, tamper-resistant evidence chain. This ensures every violation is fully traceable and legally defensible.

Dual Signal Recognition for Maximum Accuracy

Milesight Red Light Traffic Camera combines signal controller integration and AI-based video analysis to verify traffic light status. This dual-layer mechanism ensures higher reliability, especially in complex lighting or intersection environments.

Flexible Violation Logic Configuration

Users can configure multiple detection rules based on local regulations and intersection layouts. This flexibility allows authorities to tailor enforcement logic for different traffic scenarios, including straight, left-turn, and right-turn lanes.

Automated Evidence Generation

Once a violation is detected, Milesight Red Light Enforcement Camera automatically generates structured evidence packages, including snapshots, metadata, and video recordings. This eliminates manual review and significantly improves operational efficiency.

Third-Party Platform Integration

Milesight supports seamless integration with external traffic management and citation platforms. This enables end-to-end automation from detection to enforcement processing.

Unique Traffic Signal Fault Detection

Beyond violation enforcement, Milesight Red Light Traffic Camera continuously monitors traffic signal health and detects abnormal conditions such as simultaneous illumination, full outage, and flashing faults—capabilities rarely found in conventional red light cameras.

Designed for Smart City and ITS Deployments

Built for modern intelligent transportation systems, the solution is optimized for scalability, reliability, and long-term urban deployment, supporting the evolution of smarter and safer cities.

Milesight DualVision TrafficX Enforcement Camera

Red Light Violation Detection

Multiple Traffic Light Detection Methods: Based on Image or Signal Inputs

2*5MP Dual-lens for Overview and ANPR Image

99% Capture Rate & 98% Plate Recognition Rate

Global Shutter for Motion-Free Image

50m ANPR Distance & 2-3 Lanes Covering

Support 1TB SD Card for Edge Storage

4G LTE Network (Optional) & Built-in GPS
